Long Coupled Screw Pumps for Fuel & Oil Transfer
Castle Pumps have been supplying screw pumps for over 10 years, helping hundreds of clients find the right solution for their application. Our high quality long coupled screw pumps can handle lubricating fluids under fluctuating flow rates, pressures and viscosities without losing efficiency. Our range includes long coupled screw pump models with high pressure and high flow capabilities ideal for high pressure applications such as fuel oil boosting and high flow for transferring large quantities of cargo unloading and bulk storage tank transfer. Being long coupled, our screw pumps are easier to maintain and are also more durable for continuous use as they have additional bearings in the pump head to share the strain of operation.
products
- Max Flow Rate: 190M³H
- Max Head: 120M
- Max Temperature: 160°C
- Max Viscosity: 1500 cP
- Solids: 0mm
- Size: DN125 to DN150
- Max Flow Rate: 30M³H
- Max Head: 500M
- Max Temperature: 100°C
- Max Viscosity: 1500 cP
- Solids: 0mm
- Size: DN25 to DN65
- Max Flow Rate: 190M³H
- Max Head: 120M
- Max Temperature: 160°C
- Max Viscosity: 1500 cP
- Solids: 0mm
- Size: DN125 to DN150
- Max Flow Rate: 450M³H
- Max Head: 120M
- Max Temperature: 100°C
- Max Viscosity: 1500 cP
- Solid: 0mm
- Size: DN200 to DN250
- Max Flow Rate: 190M³H
- Max Head: 160M
- Max Temperature: 160°C
- Max Viscosity: 1500 cP
- Solids: 0m
- Size: DN25 to DN150
- Max Flow Rate: 450M³H
- Max Head: 120M
- Max Temperature: 100°C
- Max Viscosity: 1500 cP
- Solids: 0mm
- Size: DN200 to DN250
- Max Flow Rate: 450M³H
- Max Head: 120M
- Max Temperature: 160°C
- Max Viscosity: 1500 cP
- Solids: 0mm
- Size: DN125 to DN150
- Max Flow Rate: 190M³H
- Max Head: 120M
- Max Temperature: 160°C
- Max Viscosity: 1500 cP
- Solids: 0mm
- Size: DN125 to DN150
- Max Flow Rate: 190M³H
- Max Head: 120M
- Max Temperature: 160°C
- Max Viscosity: 1500 cP
- Solids: 0mm
- Size: DN125 to DN150
- Max Flow Rate: 30M³H
- Max Head: 500M
- Max Temperature: 100°C
- Max Viscosity: 1500 cP
- Solids: 0mm
- Size: DN25 to DN65
- Max Flow Rate: 190M³H
- Max Head: 120M
- Max Temperature: 160°C
- Max Viscosity: 1500 cP
- Solids: 0mm
- Size: DN125 to DN150
- Max Flow Rate: 450M³H
- Max Head: 120M
- Max Temperature: 100°C
- Max Viscosity: 1500 cP
- Solids: 0mm
- Size: DN200 to DN250
FAQs
Triple screw pumps consist of a driving screw and two idler screws. The motor shaft rotates the driving screw which in turns rotates the intermeshing twin idler screws that the fluid passes along.
Screw pumps are ideal for handling fuels, oils and lubricants, thanks to their ability to maintain efficiency regardless of fluctuations in viscosity. As lubricating fluids' viscosities are susceptible to change as their temperature changes, the performance of a screw pump is able to remain consistent.
When it comes to fuel and oils, gear pumps are a more known technology, when infact screw pumps have a lot of benefits. They have a smaller footprint in comparison, provide a less turbulent smoother flow, less noise and vibrations and better mechanical efficiency. For a more detailed comparison read our article https://www.castlepumps.com/info-hub/screw-pumps-vs-gear-pumps
Unlike other positive displacement pumps, screw pumps cannot handle solids so waste oils are usually avoided unless used with a strainer/filter.
Yes upon request. Being able to operate in both directions makes these screw pumps ideal for tank to tank transfer as well as returning excess liquid out of the pipework when transfer is complete.
Yes! All Azcue triple screw pumps are marine type approved by classification societies including Lloyds, Bureau Veritas and ABS. They are also suitable for low sulphur fuel down to 0.1% in line with the 2020 Global Sulphur Cap.
Our Azcue screw pumps are available with optional magnetic coupling. The absence of a mechanical seal to couple the pump and motor eliminates the chance of leaks caused by wear, which is often desirable when the fuel being pumped is flammable.
Yes, screw pumps have excellent suction capabilities without need for a manual priming device.
